Characteristics of LGY series minitype screw air compressor

An environment friendly and highly reliable minitype screw air compressor is launched by making full use of Kaishan’s own strong technological advantages in combination with characteristics of domestic minitype piston air compressors. This series tends to be more humanized and professional and it will provide you with great convenience.

Advanced design concept.

Highly reliable. The warranty period for the main engine is three years and for the entire machine is one year.

Energy saving; The screw assembly of the latest design has the highest efficiency in the industry.

Low noise; It provides quiet working environment.

Environmental protection; With leakage free design, it has low oil consumption.

Easy maintenance It has compact structure, beautiful appearance, long maintenance interval and low cost.

Specification of KAISHAN LGY Mining Screw Air Compressor

Model	Working pressure (Mpa)	Capacity m3/min	Power (KW)	Outlet	Weight (kg)	Dimension (mm)
LGY-2.8/8(with tank)	0.8	2.8	15	G1*2	350	1485×815×1005
LGY-3.6/6(with tank)	0.6	3.6	18.5	G1*2	430	1510×905×1150
LGY-4.5/6(with tank)	0.6	4.5	22	G1*2	440	1540×905×1150
LGY-4.8/10(with tank)	1	4.8	30	G1*2	470	1540×905×1150
LGY-5/7(with tank)	0.7	5		G1*2	470	1540×905×1150
LGY-5/7G(with tank)	0.7	5		G1*2	540	1815×905×1215
LGY-7.6/6(with tank)	0.6	7.6	37	G1*2	830	1950×960×1405
