KAISHAN Mining Engineering Piston Air Compressor
Home » Products » Air Compressor » KAISHAN Mining Engineering Piston Air Compressor

Variety scope: more than 100 products of fixed and mobile type; air cooling and water cooling type; diesel and electric type.

Compressor of this series is reciprocating piston air compressor which mainly provides compressed air for pneumatic tools and pneumatic control system. It is extensively used in mining, machine manufacturing, civil engineering, food, textile, bridge and road construction, and petrochemical industry.

The machine is equipped with single cylinder diesel or small motor, thus it is compact, portable and suitable for breaking road surface with the help of air pick and for secondary crushing in mine with the help of rock drill.

Technical Parameters of KAISHAN Mining Engineering Piston Air Compressor

Model

Supporting Power (kW)

Capacity(m3/min)

Working pressure(Mpa)

Dimensions (long×width×high)

W-1.35/5-D

11

1.35

0.5

1390×640×980

W-1.35/5

S1100

1.35

0.5

1390×640×980

W-1.8/5-J-D

11

1.8

0.5

1700×710×1000

W-1.8/5-J

S1100

1.8

0.5

1700×710×1000

W-1.8/5-D

11

1.8

0.5

1700×710×1000

W-1.8/5

S1100

1.8

0.5

1700×710×1000

W-2/5-D

11

2

0.5

1700×810×1050

W-2/5

S1100

2

0.5

1700×810×1050

W-2.6/5-D

15

2.6

0.5

1780×870×1235

W-2.6/5

S1110

2.6

0.5

1780×870×1235

W-2.8/5-D

15

2.8

0.5

1780×870×1235

W-2.8/5

S1110

2.8

0.5

1780×870×1235

W-2.8/5-G-D

15

2.8

0.5

1780×870×1235

W-2.8/5-G

S1115

2.8

0.5

1780×870×1235

W-2.8/5-G-DZ

15

2.8

0.5

1780×870×1235

W-3/5-D

18.5

3

0.5

1800×900×1300

W-3/5

S1115

3

0.5

1800×900×1300

2V-3.5/5-D

18.5

3.5

0.5

1800×950×1300

2V-3.5/5

S1125

3.5

0.5

1800×950×1300

2V-4/5-D

18.5

4

0.5

1800×950×1300

2V-4/5

S1125

4

0.5

1800×950×1300

W-1.8/7-D

11

1.8

0.7

1100×820×1100

W-1.8/7

S1100

1.8

0.7

1100×820×1100

W-2.6/7-D

15

2.6

0.7

1800×870×1235

W-2.6/7

S1115

2.6

0.7

1800×870×1235

W-3.2/7-D

18.5

3.2

0.7

1920×960×1350

W-3.2/7

S1125

0.7

0.7

1920×960×1350

W-2.5/3-D

11

2.5

0.3

1780×870×1235

W-2.5/3

S1110

2.5

0.3

1780×870×1235

VF-3/7

18.5

3

0.7

1720×1100×1110

VF-6/7

37

6

0.7

2100×1100×1110

VFY-6/7

37

6

0.7

2830×1500×1890

VF-7/7

40

7

0.7

2100×1100×1110

CVF7/7

YC4108

7

0.7

2760×1200×1460

CVF7/7

QC4110

7

0.7

2760×1200×1460

VFY-7/7

40

7

0.7

2830×1500×1890

CVFY-7/7

YC4108

7

0.7

2830×1300×1890

CVFY-7/7

QC4110

7

0.7

2830×1300×1890

VF-9/7

55

9

0.7

2460×1200×1220

VFY-9/7

55

9

0.7

2830×1500×1900

VF-10/7

63

10

0.7

2460×1200×1220

VFY-10/7

63

10

0.7

2830×1500×1900

CVF-10/7

YC4108ZG

10

0.7

3200×1350×1650

CVF-10/7

QC4112

10

0.7

3200×1350×1650

CVFY-10/7

YC4108ZG

10

0.7

3200×1550×2230

CVFY-10/7

QC4112

10

0.7

3200×1550×2230

VF-13/7

75

13

0.7

2460×1200×1220

VFY-13/7

75

13

0.7

2830×1500×1900

CVF-13/7

YC6108ZG

13

0.7

3300×1350×1470

CVF-13/7

CUMMINS6BT5.9-C118

13

0.7

3300×1350×1470

CVF-13/7

QC6112

13

0.7

3350×1350×2100

CVFY-13/7

YC6108ZG

13

0.7

3500×1600×2640

CVFY-13/7

CUMMINS6BT5.9-C118

13

0.7

3500×1600×2340

CVFY-13/7

QC6112

13

0.7

3570×1600×2640

2V-6/7

37

6

0.7

1750×1100×1200

2V-7/7

40

7

0.7

1750×1100×1200
