Rock rigidity

f=6-20

Total weight

6000kg

Drilling diameter

φ80-125mm

Dimensions

5355x2215x2365mm

Economic drilling depth

25m

Guide tilt

Look down135° Looking up 5° Altogether 145°

Rotation speed

120r/min

Guide swinging angle degrees

Left 100° right 45° Altogether 145°

Rotary torque

2000N.m

Drill boom pitch angle

Look down50° Looking up 25° Altogether 75°

Lifting force

17000N

Drill boom arm angle

Left 45° right 90° Altogether 135°

Propulsion mode

Cylinders - Chain

GuideCompensation length

1200mm

Feed length

3000mm

Power

YC4D80(58kW2400r/min)

Travel speed

0-2.0km/h

Drill rod

φ76×3000

Climbing capacity

30°

Pression d’air de travail

1.0-2.4MPa

Ground clearance

320mm

Air consumption

9-18m³/min
